Manual Hydraulic Floor Crane FI-019 |
|
| We provide an extensive range of floor crane in different capacities with remarkable versatility for a wide range of jobs. These floor cranes are designed and developed by us for greater mobility and easy application. With large diameter steel wheels and dual swivel casters with pivoted steering handle, positioning is quick, easy and accurate with less operator workload. |
 |
Capacity |
: |
500 Kgs to 3000 Kgs. |
Overall length |
: |
1450 to 2100 mm. |
Over all width |
: |
1000 to 1260 mm. |
Over all Ht |
: |
1550 to 2100 mm. |
Lowest Hook ht |
: |
300 to 450mm. |
Highest Hook ht |
: |
2700 to 3400mm. |
Min Boom length |
: |
1250 to 1450 mm. |
Max Boom Length |
: |
1550 to 1900 mm. |
Wheel Dia |
: |
200 mm. |
|
Inquiry for Manual Hydraulic Floor Crane FI-019
|
|
|
|
|
Rotated Hydraulic Floor Crane FI-020 |
|
 |
Product Specification :
|
| We are engaged in offering quality range of Rotated Hydraulic Floor Crane in compliance with the international products. Our high Rotated Hydraulic Floor Crane is capable of bearing heavy loads and finds usage in various industries. Our range can be customized in different configurations and specification to meet the client's requirements. |
|
|
Inquiry for Rotated Hydraulic Floor Crane FI-020
|
|
Counter Balance Floor Crane (New) |
|
 |
It is effectively a workshop floor crane with traditional style jib crane mounted the the front of the crane. It has an integrated push travel trolley permanently fitted into the horizontal lifting beam (The cantilever jib arm). The load trolley can be positioned anywhere on the jib arm, for example above the item to be lifted, when the weight is taken the suspended load can then be moved along the jib arm without moving the crane chassis. The load trolley has a manual locking mechanism so that it can be locked in any position. All mobile jib cranes with this style of movable trolley in the jib arm are made to our customers specification, SWL (capacity) height of lift and reach of jib arm etc... All can be supplied with a great deal of additional features to meet with our customer exact requirements; one of the most poplar enhancements is the rotating jib arm which allows the arm to rotate 15 degrees ether side of centre.
Note :
The pictures shown are our artists impression only and are only indicative of our capability. (for display purposes only) All cranes are made individually and the the design may be subject to change according to your required specification; the pictures are not to scale, general arrangement drawings will be issued for approval on receipt of your order.
Stainless steel option is also available, please phone or request a quote by clicking on to the BUY/Quote tab |
Some optional features to the crane are : (also see Optional Features tab above)
- Removable vertical jib column to assist packing for export orders.
- Vertical telescopic mast adjustment.
- Excellent range of capacities and specials to customers requirements: 152kg, 254kg, 508kg, 750kg, 1000kg and 2000kg
- Brakes with locking Castor's and directional locking Castor's / wheels.
- Electric power 12v DC battery drive / propulsion.
- Choice of lifting equipment suspended from the crane, manual, electric or pneumatic
- Outriggers on the crane body to ensure a stable lift at height.
- Certified lifting points for the ability to have crane lifted / moved by an overhead crane.
- Fork truck pockets, to enable the counterbalanced floor crane to be moved by a fork truck.
- Jacking feet to give a level and stable lift.
- Rotating vertical jib arm, will rotate 15 degrees either direction .
- Please see the Images Tab above for pictures of these features.
- Come with a 12 month guarantee.
Important Safety Information :
- Always inspect hook and latch before using.
- Never use a latch that is distorted or bent.
|
Inquiry for Counter Balance Floor Crane (New)
|
|
|
|
| Available with us is a gamut of Portable Gantry Cranes that can be easily moved from one place to another and are primarily used for picking, transporting and rotating the load. These gantries can be rolled inside or outside as per the requirement and can be used anywhere on a smooth and leveled surface. |
 |
Features:
Steel or aluminum, fixed or adjustable, Posi-Gantri head beam, along with a selection of accessories.
Available lifting height : upto 10000 mm.
Available options : Span length, lifting height, size to suit the specific application.
Available Options : Manual, Electric operated & Battery operated. |
Inquiry for Portable Gantry FI-043
|
|
|
| |
|
 |
We are engaged in manufacturing a range of Jib Crane that is designed and developed using latest technology and quality components. These Jib Cranes have a rotating boom to a mast and ceiling mounting. The rotating boom is held in a vertical position by floor and the ceiling mounting by wall bracket mounting. ,Jib crane stands for superior quality product. They are an important part of any material handling system. They help reduce labor cost by avoiding the time lost on waiting for an overhead crane or forklift. A Jib crane can be easily handled by one person and is very cost-effective. By combining lightweight construction techniques we have developed a Jib crane that is not only lightweight but produces minimum amount of friction thus reducing operator fatigue and wear and tear. |
MODEL |
LIFTING CAPACITY (KG.) |
FI-044 |
500 |
FI-044 |
1000 |
FI-044 |
2000 |
FI-044 |
3000 |
|
Features :
- "Premier" Heavy Duty Jib Cranes are base mounted; self supported jib cranes with thick base plate mounting on a concrete foundation with 220° rotation of jib arm.
- These types of cranes are widely used in Fabrication Shops, Machine Shops, Assembly Shops, loading & unloading purposes and can be used both indoor as well as outdoor applications.
- A set of taper roller bearing in combination with thrust bearing, one set at bottom and one set at top take care of horizontal and vertical load as well as radial thrust.
- Jib cranes are available with hand operated or electrically operated chain pulley block for vertical lifting and chain operated or electrically operated gear trolley for horizontal movement of load.
- Special polyurethane shock absorber or buffers are provided at extreme ends as a standard feature.
|
Inquiry for Jib Crane FI-044
|
|
|
|
|
|
|
|
