Goods Lift

Goods Lift
Used for various material handling applications such as material shifting from shop floor to up stairs and maintenance work, we offer a wide range of Hydraulic Goods Lift (Two Channel Guide). These are controlled with height limit switches and provided with mechanical stoppers that increase the efficiency of the Lift. To suit the varied requirements of the clients, we can also offer the customized range of the lift within committed time frame.

Features:

  • Capacity: 500 & 1000 Kg.

  • Lift: Upto 6 Mtr.

  • Used for material shifting from shop floor to up stairs.

  • These are self standing lifts & no civil work like duct is needed.

  • Up & down movement with fully automatic Electro Hydraulic Power Pack.

  • Adjustable overload protection valve gives safety against overloading.

  • Power pack is on ground for easy maintenance work.

  • Up & down movement are controlled by height limit switches in addition to mechanical stoppers.

  • Occupies small space on shop floor.

  • Two lifting chains & 2 stand by ropes are provided as standard features.

MODEL

 Fi-046

Load Carrying Capacity (kg)

500

Max. Platform Height H1 (mm)

4000

Min. Platform Height H2 (mm)

125

Platform Length L (mm)

1200

Platform Width W (mm)

1200

Overall Width W1 (mm)

1700

Overall Height H3 (mm)

6000

Cage Height H4 (mm)

1500

Inquiry for Goods Lift

Name

  Required


Personal Lift
ADVANTAGES OF FUTURE INDUSTRIES :
This lift don't required Head room or Pit. Power required only while going up. In case of power failure you can come down-manually. This will work on Single phase also if reqd. This can be fitted even on old buildings also. General lifts are not available for one floor. Cost of pillars & side walls can be saved.
HOW DOES IT WORK :
A hydraulic lift is a lift operated by the weight or pressure of oil. It integrates easily with most architectural designs and has long operational life with minimal maintenance, ride comfort and totally safe operation. It has a cost-effective and installation design.

They are designed with safety factors for excess load conditions and are equipped with long life ball bearings. For smaller and medium sized installations the cantilevered sling in combination with a single acting cylinder offers the best elevator application
TECHNICAL SPECIFICATIONS :
Load capacity : 1000 Kgs.
Type of lift : Cabin type  freight lift.
Cabin size : 900 mm (length) X 900 mm(width) 14 Ft  (height).
Area needed : JUST 1200 mm X 1000 mm.
Raise Heigh : 14 Ft.

Lower Height : Lifting by three Phase with A.C.
Operating system   : Platform carriage is lifted by hydraulic cylinder.
Lifting system : Installation Area is 1200 mm X 1000 mm.
Space Required For lift : Installation Area is 1200 mm X 1000 mm.
Electric system : The electric panel is  M. S.  L & T   startercontractors  and  overload relay, MCB’s, up buttons , Limit switches & Terminal strip. The control cabinet is mounted within the power pack at the ground level.
Controls    : UP,  DOWN and EMERGENCY STOP Will be controlled through push buttons provided inside the cabin ,the lift will stop automatically on the platform reaching desired Floor level by actuation of pre-adjusted leveling limit switches.
Painting            : All structural components to be painted by One coat of  red  - oxide  primer and final coat of grey  The body of  the Hydraulic lift Golden yellow while Hydraulic  parts in black.
