Material handling equipment manufacturer


Future Industries
Material Handling Equipments Manufacturer in Ahmedabad - Gujarat - INDIA

An ISO 9001:2008 Company		 ISO

Hydraulic Lifting Equipments

Die Loader (Scissor - Trolley) FI-001
Die Loader (Scissor - Trolley) FI-001 Future Industries - Ahmedabad is manufacturer, supplier and exporter of various types of Hydraulic Scissors Lift Tables for hoisting and lifting operations for various heights and industry types. Hydraulic Scissors Lift Tables manufactured by us are dependable, strongly built and entirely safe for any kind of lifting operation.

FUTURE INDUSTRIES  dependable Hydraulic Scissors Lift Tables are made from the best steel with state-of-the-art expertise and machinery. The precision manufacturing process employed ensures that each of our Scissors Lift Tables is up to international standards and specifications. Our Hydraulic Scissors Lift Tables come in a range of styles from common standard to customer-defined lifts. Our Hydraulic Scissors Lift Tables have different table sizes and weight loading capacities. Our scissors lift tables are known for their little or no maintenance costs and ease of handling.
 Die Loader with Convar (Double Scissor)
Capacity in Ton Top Table Size Closed Height Raised Height Wheel
1/2 Ton 500X700 300 1000 Nilon Wheel
1/2 Ton 500X700 410 1600 Nilon Wheel
1/2 Ton 500X900 365 1250 Nilon Wheel
1 Ton 500X900 365 1250 Nilon Wheel
1 Ton 600X900 365 1250 Nilon Wheel
1 Ton 600X1000 365 1500 Nilon Wheel

Inquiry for Die Loader (Scissor - Trolley) FI-001

Name

  Required.


Die Loader (Scissor - Trolley) FI-002
We are manufacturers, suppliers and exporters of various types of Hydraulic Scissors Lift Tables for hoisting and lifting operations for various heights and industry types. Hydraulic Scissors Lift Tables manufactured by us are dependable, strongly built and entirely safe for any kind of lifting operation.

FUTURE INDUSTRIES  dependable Hydraulic Scissors Lift Tables are made from the best steel with state-of-the-art expertise and machinery. The precision manufacturing process employed ensures that each of our Scissors Lift Tables is up to international standards and specifications. Our Hydraulic Scissors Lift Tables come in a range of styles from common standard to customer-defined lifts. Our Hydraulic Scissors Lift Tables have different table sizes and weight loading capacities. Our scissors lift tables are known for their little or no maintenance costs and ease of handling.
Die Loader with Convar (Double Scissor)
Capacity in Ton Top Table Size Closed Height Raised Height Wheel
1/2 Ton 500X700 300 1000 Nilon Wheel
1/2 Ton 500X700 410 1600 Nilon Wheel
1/2 Ton 500X900 365 1250 Nilon Wheel
1 Ton 500X900 365 1250 Nilon Wheel
1 Ton 600X900 365 1250 Nilon Wheel
1 Ton 600X1000 365 1500 Nilon Wheel

Inquiry for Die Loader (Scissor - Trolley) FI-002

Name

  Required.


Hydraulic Scissor Lift Table FI-003
FUTURE INDUSTRIES   offers a wide range of Lift Tables in advanced features to cater to vast requirements of clients. The AHLT Lift Table provided by us is safe & efficient and ways to endless Material Handling Applications at Distribution Center, Logistics Companies, Industries etc. Our Lift Tables are popular in the market because we don’t compromise on the quality and always endeavor to meet International Standards by stringent quality checking and using State-of-the-art Technologies in the manufacturing process.
  Feature :
  • Remote power pack with 4 mtr Hydraulic Hose.
  • Push button control on 3.5 mtr cable.
  • Hydraulic pump with built in overload relief.
  • Full length deck beam for maximum support.
  • Solid plate scissor legs for maximum rigidity.
  • Chequered Plate deck and   lip with chain.
  • All pivot points equipped with lubricated nipples.
  • Lowering brake valve to prevent platform free fall.
  • Completely sealed, weather resistant glinders and piston.
  • Motor, controls, push button factory pre wired and tested.
 Power Double Scissor Lift (Capacity 1/2 Ton to 3 Ton)
Table Size Closed Height Lift Raised Height Capacity
1200x750 400 1400 1800 3/5 Ton
1500x1000 400 1800 2200 3 Ton.
1800x1000 450 2100 2550 1500 Kgs.
2200x1200 500 2600 3100 1 Ton
2500x1500 500 3000 3500 1 Ton
3000x1500 600 3500 4100 1 Ton
3500x1500 600 4200 4800 1 Ton

Hydraulic Scissor Lift Table FI-003

Name

  Required.


 Movable Scissor Lift Table FI-004
We are offering to our clients, Heavy Duty Scissor Lift Tables, which are ideal for heavy duty application under the toughest working conditions. These have scissor leg rollers, entrapped within the structure of the platform and base frame to ensure maximum unit stability on all four sides.
Capacity : 500  Kgs.
Minimum Height : 1000  mm.
Maximum Height : 7000  mm.
Top Tabl Size : 2500  mm. L X 2000  mm. W ( With Pipe Railing Guard )
Type : Four Scissor. Manual Hydraulic. Mobile Version.
Side Stabilizers : 4 Nos. Manual Operated.
Hydraulic Unit : 2 Nos. Inclined Mounted Honned Hyd. Cylinder With Hard-Chrome Plated Piston Which is Actuated By 1 No. “Dowty” Make Double Acting Hyd. Pump.
Structure : Base & Top Table Structure Will Made From M.S. ‘C’ Channel Section. 2 Nos. Scissors Are Made From Heavy-Duty M.S. Box  Section. Platform Is Covered By M.S. Sheet.
Handle : 1 No. Inverted ‘T’ Shape Toeable Type M.S. Pipe Handle For Push- Pull Purpose.
Paint : One Coat Of Primer & Two Coats Of Auto-Finish Paint.

   Feature :
  • Remote power pack with 4 mtr Hydraulic Hose.
  • Push button control on 3.5 mtr cable.
  • Hydraulic pump with built in overload relief.
  • Full length deck beam for maximum support.
  • Solid plate scissor legs for maximum rigidity.
  • Chequered Plate deck and   lip with chain.
  • All pivot points equipped with lubricated nipples.
  • Lowering brake valve to prevent platform free fall.
  • Completely sealed, weather resistant glinders and piston.
  • Motor, controls, push button factory pre wired and tested.
 Power Double Scissor Lift (Capacity 1/2 Ton to 3 Ton)
Table Size Closed Height Lift Raised Height Capacity
1500x1000 600 1600 2000 500-5000 Kgs.
1800x1000 600 2100 2550 500 Kgs.-2 Ton
2200x1200 700 2600 3100 1- 2 Ton
2500x1500 700 3000 3500 1 Ton
3000x1500 800 3500 4100 1 Ton
3000x2000 900 5000 6000 1 Ton

 Movable Scissor Lift Table FI-004

Name

  RequiredRequired.


Movable Scissor Lift Table FI-005
We are manufacturers, suppliers and exporters of various types of Hydraulic Scissors Lift Tables for hoisting and lifting operations for various heights and industry types. Hydraulic Scissors Lift Tables manufactured by us are dependable, strongly built and entirely safe for any kind of lifting operation.

FUTURE INDUSTRIES  dependable Hydraulic Scissors Lift Tables are made from the best steel with state-of-the-art expertise and machinery. The precision manufacturing process employed ensures that each of our Scissors Lift Tables is up to international standards and specifications. Our Hydraulic Scissors Lift Tables come in a range of styles from common standard to customer-defined lifts. Our Hydraulic Scissors Lift Tables have different table sizes and weight loading capacities. Our scissors lift tables are known for their little or no maintenance costs and ease of handling.

 Movable Scissor Lift Table FI-005

Name

  RequiredRequired.


Pit Mounted Scissor Lift Table FI-006
FUTURE INDUSTRIES   offers a wide range of Lift Tables in advanced features to cater to vast requirements of clients. The AHLT Lift Table provided by us is safe & efficient and ways to endless Material Handling Applications at Distribution Center, Logistics Companies, Industries etc. Our Lift Tables are popular in the market because we don’t compromise on the quality and always endeavor to meet International Standards by stringent quality checking and using State-of-the-art Technologies in the manufacturing process.

   Feature :
  • Remote power pack with 4 mtr Hydraulic Hose.
  • Push button control on 3.5 mtr cable.
  • Hydraulic pump with built in overload relief.
  • Full length deck beam for maximum support.
  • Solid plate scissor legs for maximum rigidity.
  • Chequered Plate deck and   lip with chain.
  • All pivot points equipped with lubricated nipples.
  • Lowering brake valve to prevent platform free fall.
  • Completely sealed, weather resistant glinders and piston.
  • Motor, controls, push button factory pre wired and tested.
 Power Double Scissor Lift (Capacity 1/2 Ton to 3 Ton)
Table Size Closed Height Lift Raised Height Capacity
1500x1000 600 1600 2000 500-5000 Kgs.
1800x1000 600 2100 2550 500 Kgs.-2 Ton
2200x1200 700 2600 3100 1- 2 Ton
2500x1500 700 3000 3500 1 Ton
3000x1500 800 3500 4100 1 Ton
3000x2000 900 5000 6000 1 Ton

 Pit Mounted Scissor Lift Table FI-006

Name

  Required.Required.


Lifting Table

We are manufacturers, suppliers and exporters of various types of Hydraulic Power Scissors Lifts for hoisting and lifting operations for various heights. Hydraulic Power Scissors Lifts manufactured by us are secure, sturdy and dependable. Hydraulic Power Scissors Lifts are made from the best mild steel with state-of-the-art technology. The precision manufacturing process ensures that each of our products is up to our valued customers standards and order parameters. Our Hydraulic Power Scissors Lifts come in a range of customer-defined or customized styles. Our Scissors Lifts have different weight loading capacities and are of different types. Our lifts are known for their low maintenance costs and smooth and easy operational handling
 Power Single Scissor Lift
(Capacity 1/2 Ton to 5 Ton)

Table Size

Closed Height

Lift

Raised Height

1200x750

300

700

1000

1800x1000

350

1050

1400

2200x1200

400

1300

1700

2500x1200

400

1500

1900

3000x1500

450

1800

2250

3500x1500

500

2100

2600

4000x1500

600

2400

3000
 Power Double Scissor Lift
(Capacity 1/2 Ton to 3 Ton)

Table Size

Closed Height

Lift

Raised Height

1200x750

400

1400

1800

1500x1000

400

1800

2200

1800x1000

450

2100

2550

2200x1200

500

2600

3100

2500x1500

500

3000

3500

3000x1500

600

3500

4100

3500x1500

600

4200

4800

Lifting Table

Name

  RequiredRequired.
