Electrical Hydraulic Stacker FI-012 |
|
 |
Our company has also specialized in the field of manufacturing and supplying a wide range of Semi Electric Stacker's (24V Battery & DC Supply) that are available with load centre: 600 mm, lifting speed: 0.08 m/sec and fork length: 1100 mm. Further, our wide range of Semi Electric Stacker's is available in counter balanced type (cap. 500kg) as well as in straddle leg stacker's with adjustable forks (cap. 500 & 1000 kg.). |
Specifications:
- Capacity : 500 & 1000 kg.
- Lift : 1 500, 2500 & 3000 mm.
- Load Center - 600 mm.
- Lifting Speed - 0.08 m/sec.
- Fork Length - 1100 mm.
- Width over forks - 540 mm.
- Overall size - L 1700 x W 700 mm.
- Front wheels - diameter 82 x 96 mm - 2 Nos.
- Steering wheels – diameter 200 x 50 mm – 2.
|
Features:
- Up & Down movement with 24 V Battery & manual pulling & pushing.
- 3 HP, 24 V DC electric motor for lifting with Dowty make oil gear pump.
- Provided with r BCK make adjustable height limit switch
- Operated by 24 V heavy duty contractor.
- Lever operated directional control valve with inbuilt pressure relief valve for up & down movement.
- Oil tank with oil level indicator, oil breather and suction strainer.
- Battery - 24 V, 85 Amp - Hr, Tubular monoblock
- A separate 24 V DC, 230 V AC battery charger is needed to charge a battery.
|
Lifting capacity
(kg) |
Max. fork height
H1 (mm) |
Win. fork height
H2 (mm) |
Min. Overall Height
H3 (mm) |
Max. Overall Height
H4 (mm) |
| 500 |
1500 |
100 |
1600 |
2300 |
| 500 |
2500 |
100 |
2100 |
3300 |
| 500 |
3000 |
100 |
24 |
3900 |
| 1000 |
1500 |
100 |
1600 |
2300 |
| 1000 |
2500 |
100 |
2100 |
3000 |
| 1000 |
3000 |
100 |
2400 |
3900 |
|
Inquiry for Electrical Hydraulic Stacker FI-012
|
|
|
|
|
Manual Hydraulic Stacker FI-013 |
|
 |
We, the Material Handling Equipments solutions provider offer unique range of Hand Stackers at competitive price range. Our Hand Stackers provides a safe and efficient way to endless material application at Distribution Center, Logistics Companies, Industries etc. |
| Features: |
- Basic capacity from 500 kg – 1500 kg.
|
- Lift heights: Mono and telescopic masts from 1400 mm – 3000 mm.
|
- Special Fork Length & Width.
|
|
- Pump assembly includes neutral position for controlled handling of load.
|
- Pistons and cylinder are hard chrome Plated.
|
- Double sealed high pressured polyurethane seals are used to prevent leakage.
|
- Industry’s Best Warranty - 1 year.
|
- Lifting speed – 14 mm/stroke.
|
- Our Stackers are suitable, where lifting is primary and the transport distance is short.
|
|
| Maximum Fork Heightt (mm) h3 |
Lower
Height |
Overall Height
(mm) h1 |
Extended Mast Height
(mm) h4 |
Capacity at
600mml.
c(kg)z |
| 1600 |
90mm |
2000 |
2000 |
1 Ton |
| 2450 |
90mm |
1780 |
2920 |
1 Ton |
| 2850 |
90mm |
1980 |
3320 |
1 Ton |
| 3100 |
90mm |
2100 |
3570 |
1 Ton |
| 3350 |
90mm |
2230 |
3820 |
1 Ton |
| 3600 |
90mm |
2350 |
4070 |
1 Ton |
| 3900 |
90mm |
2500 |
4370 |
1 Ton |
| 4200 |
90mm |
2650 |
4670 |
1 Ton |
| 1000 |
90mm |
1200 |
1000 |
2.5 Ton |
|
Inquiry for Manual Hydraulic Stacker FI-013
|
|
|
Manual Hydraulic Stacker (Counter Balance) FI-014 |
|
 |
We offer our clients an assortment of Counter Balance Hydraulic Stacker that is fabricated using high quality raw material and is offered at industry leading prices. Safe to use, these stackers are precision engineered to ensure their efficient performance and durability. Our range of counter balance stacker is designed to effectively carry out various applications such as lifting and transporting skids, bales and baskets. It also helps in the loading and unloading trucks, stocking shelves, die and mold handling. |
Specifications:
• Available capacity: From 100 Kgs to 1000 Kgs.
• Available lifting height: Single Mast, Double Masts, Triple masts from 200 mm-4000 mm.
• Available Options: manual, Electric operated & battery operated.
• Choice: special fork length, width, wheels & capacity as per requirement. |
Inquiry for Manual Hydraulic Stacker (Counter Balance) FI-014
|
|
|
Manual Hydraulic Roller Stacker FI-015 |
|
 |
| Structure |
: |
Simplex Design Single Mast Structure Made From ‘C’ Channel Section, Supported By Heavy-Duty Deep Grooved Guide Rollers. Forks Lifted By Means Of 2 Nos. Simplex Chain & Pulley Design. |
| Hydraulic Unit |
: |
1 No. Vertical Mounted,Single Acting,Honned Hyd. Cylinder With Hard-Chrome Plated Piston Which Is Actuated By 1 No. Hydraulic Single Acting Hand Pump. |
| Wheels |
: |
2 Nos. 200x50 mm. Size White Virgin Nylon Wheels At Front (Handle) Side & 4 Nos. 150 X 50 mm. Size Load Roller Wheels At Rear Side. All Wheel Contains Double Ball Bearings For Easy Movement Of Stacker. |
| Handle |
: |
Inverted ‘U’ Shape Handle For Push-Pull Action Of Stacker. |
| Paint |
: |
One Coat Of Primer & Two Coats Of Auto-Finish Paint. |
|
Inquiry for Manual Hydraulic Roller Stacker FI-015
|
|
|
| |
Battery Operated Hydraulic Stacker FI-016 |
|
 |
Leveraging on our vast industry experience, we are able to provide our clients a gamut of Stainless Steel Pallet Stacker that is applicable in various areas such as cold stores, dairy, canning and all other areas where corrosive liquid and saline solutions are used. All the parts of this stacker are fabricated using high quality stainless steel, including hydraulic pump, fork frame, handle, push rod, pin and bolt.
It is enabled with an entirely sealed pump unit that incorporates an overload release valve and there is also a one-piece "C" section forks for greater strength and a highly strong chassis along inside of forks. This stacker is a safe and ergonomic alternative to fork trucks at a cheaper cost. Moreover, these stackers are accurately engineered for smooth operation and excellent durability.
These stackers can efficiently perform various functions such as lifting and transporting skids, bales, baskets, and loading unloading trucks, stocking shelves, die and mold handling.
|
Specifications:
• Available capacity: From 100 Kgs to 2000 Kgs.
• Available lifting height: Single Mast, Double Masts, Triple masts from 200 mm-6000 mm.
• Available Options: manual, electric operated & battery operated.
• Choice: special fork length, width, wheels & capacity as per requirement. |
Inquiry for Battery Operated Hydraulic Stacker FI-016
|
|
|
| |
|
|
 |
We, the Material Handling Equipments solutions provider, offer unique range of Hand Stackers at competitive price range. Our Hand Stackers provides a safe and efficient way to endless material application at Distribution Center, Logistics Companies, Industries etc. |
| Features: |
- Basic capacity from 500 kg – 1500 kg.
|
- Lift heights: Mono and telescopic masts from 1400 mm – 3000 mm.
|
- Special Fork Length & Width.
|
|
- Pump assembly includes neutral position for controlled handling of load.
|
- Pistons and cylinder are hard chrome Plated.
|
- Double sealed high pressured polyurethane seals are used to prevent leakage.
|
- Industry’s Best Warranty - 1 year.
|
- Lifting speed – 14 mm/stroke.
|
- Our Stackers are suitable, where lifting is primary and the transport distance is short.
|
|
Maximum Fork
Heightt (mm) h3 |
Lower Height |
Overall Height
(mm) h1 |
Extended Mast Height
(mm) h4 |
Capacity at
600mml.
c(kg)z |
1600 |
90mm |
2000 |
2000 |
1 Ton |
2450 |
90mm |
1780 |
2920 |
1 Ton |
2850 |
90mm |
1980 |
3320 |
1 Ton |
3100 |
90mm |
2100 |
3570 |
1 Ton |
3350 |
90mm |
2230 |
3820 |
1 Ton |
3600 |
90mm |
2350 |
4070 |
1 Ton |
3900 |
90mm |
2500 |
4370 |
1 Ton |
4200 |
90mm |
2650 |
4670 |
1 Ton |
| 1000 |
90mm |
1200 |
1000 |
2.5 Ton |
|
Inquiry for Mini Stacker FI-017
|
|
|
| |
Hydraulic Reel Stacker FI-018 |
 |
We manufacture a range of Reel Stacker that is exclusively designed for lifting Plastics Rolls, Paper Reels and Cloth Rolls, among others. These stackers are suitable for handling anything that rolls and requires to be lifted. The stacker is provided with a fork extension which ensures that it can be easily stacked above the fork limit |
Specifications:
• Available capacity: From 100 Kgs to 2000 Kgs.
• Available lifting height: Single Mast, Double Masts, Triple masts from 200 mm-6000 mm.
• Available Options: manual, electric operated & battery operated.
• Choice: special fork length, width, wheels & capacity as per requirement. |
Inquiry for Hydraulic Reel Stacker FI-018
|
|
|
| |
Battery Operated Counter Balance Stacker (new-1) |
|
.jpg) |
All the Electric Stackers manufactured and supplied by us are made of best quality material. All the Electric Stackers supplied by Our Company are adequate to meet each requirement of users. We bring you advanced ergonomics, engineering, materials and the highest quality electrical, hydraulic and mechanical components in ACER-AES series Stackers. Other features like programmable electric hand control makes these products safer, and maintenance free. |
| Features: |
- Reduced material movement and storage cost.
|
- Clear view mast gives a greater visibility.
|
- Good maneuverability in small space.
|
- For use in narrow aisles.
|
|
|
|
|
| Battery : |
|
The Battery Capacity - 24 V. |
|
180 / 206Ah/5hrs Rating - For Mono & Telescopic Stackers. |
|
240 / 330Ah/5hrs Rating - For WFFTL & SSFFTL Stackers. |
|
The battery weight 280 kgs. |
|
The battery is rested on nylon rollers for quick and effective replacement. |
|
| Electric Unit : |
|
Drive Motor : 1.6 Kw Make CFR. |
|
Lift Motor : 2.2 Kw Make HALDEX. |
|
Controller Type : MOSFET based DC Motor Speed Controller. |
|
Charger : SIRIUS Controls. |
|
| Mast Channel : |
|
Make - HOESCH. |
|
| Direction Control Valve : |
|
Make - HYDRO CONTROL. |
|
|
| Suspension : |
|
Heavy-duty suspension with 4 helical coil springs ensures the firm grip to the drive wheels for positive traction. |
|
| Wheels |
|
Steering (2 nylon wheels) – 180 mm X 50 mm. |
|
Load wheel (4 nylon wheels) – 80 mm X 72 mm. |
|
Inquiry for Battery Operated Counter Balance Stacker (new-1)
|
|
|
|
|
| |
| |
Battery Operated Counter Balance Stacker (new-2) |
|
.jpg) |
All the Electric Stackers manufactured and supplied by us are made of best quality material. All the Electric Stackers supplied by Our Company are adequate to meet each requirement of users. We bring you advanced ergonomics, engineering, materials and the highest quality electrical, hydraulic and mechanical components in ACER-AES series Stackers. Other features like programmable electric hand control makes these products safer, and maintenance free. |
| Features: |
- Reduced material movement and storage cost.
|
- Clear view mast gives a greater visibility.
|
- Good maneuverability in small space.
|
- For use in narrow aisles.
|
|
|
|
|
| Battery : |
|
The Battery Capacity - 24 V. |
|
180 / 206Ah/5hrs Rating - For Mono & Telescopic Stackers. |
|
240 / 330Ah/5hrs Rating - For WFFTL & SSFFTL Stackers. |
|
The battery weight 280 kgs. |
|
The battery is rested on nylon rollers for quick and effective replacement. |
|
| Electric Unit : |
|
Drive Motor : 1.6 Kw Make CFR. |
|
Lift Motor : 2.2 Kw Make HALDEX. |
|
Controller Type : MOSFET based DC Motor Speed Controlle. |
|
Charger : SIRIUS Controls. |
|
| Mast Channel : |
|
Make - HOESCH. |
|
| Direction Control Valve : |
|
Make - HYDRO CONTROL. |
|
|
| Suspension : |
|
Heavy-duty suspension with 4 helical coil springs ensures the firm grip to the drive wheels for positive traction. |
|
| Wheels : |
|
Steering (2 nylon wheels) – 180 mm X 50 mm. |
|
Load wheel (4 nylon wheels) – 80 mm X 72 mm. |
|
Inquiry for Battery Operated Counter Balance Stacker (new-2)
|
|
|
| |
| |
Semi Electric Hydraulic Stacker |
|
 |
Our company has also specialized in the field of manufacturing and supplying a wide range of Semi Electric Stacker's (24V Battery & DC Supply) that are available with load centre: 600 mm, lifting speed: 0.08 m/sec and fork length: 1100 mm. Further, our wide range of Semi Electric Stacker's is available in counter balanced type (cap. 500kg) as well as in straddle leg stacker's with adjustable forks (cap. 500 & 1000 kg.) |
Specifications:
- Capacity: 500 & 1000 kg.
- Lift: 1 500, 2500 & 3000 mm.
- Load Center - 600 mm.
- Lifting Speed - 0.08 m/sec.
- Fork Length - 1100 mm.
- Width over forks - 540 mm.
- Overall size - L 1700 x W 700 mm.
- Front wheels - diameter 82 x 96 mm - 2 Nos.
- Steering wheels – diameter 200 x 50 mm – 2.
|
Features:
- Up & Down movement with 24 V Battery & manual pulling & pushing.
- 3 HP, 24 V DC electric motor for lifting with Dowty make oil gear pump.
- Provided with r BCK make adjustable height limit switch
- Operated by 24 V heavy duty contractor.
- Lever operated directional control valve with inbuilt pressure relief valve for up & down movement.
- Oil tank with oil level indicator, oil breather and suction strainer.
- Battery - 24 V, 85 Amp - Hr, Tubular monoblock.
- A separate 24 V DC, 230 V AC battery charger is needed to charge a battery.
|
Lifting capacity
(kg) |
Max. fork height
H1 (mm) |
Win. fork height
H2 (mm) |
Min. Overall Height
H3 (mm) |
Max. Overall Height
H4 (mm) |
| 500 |
1500 |
100 |
1600 |
2300 |
| 500 |
2500 |
100 |
2100 |
3300 |
| 500 |
3000 |
100 |
24 |
3900 |
| 1000 |
1500 |
100 |
1600 |
2300 |
| 1000 |
2500 |
100 |
2100 |
3000 |
| 1000 |
3000 |
100 |
2400 |
3900 |
|
Inquiry for Semi Electric Hydraulic Stacker
|
|
|
|
|
|
|
