Manual Hydraulic Hand Pallet Truck FI-009 |
|
 |
 |
We offer our clients a vast assortment of Hydraulic Hand Pallet Truck that has high load bearing capacity and is provided with Polyurethane / UHMW-PE tandem rollers for quieter and smoother rolling over rough surfaces. It is also equipped with a one-piece "C" section forks for greater strength and a sully strengthened chassis along inside of forks.
The pallet truck also has bushed metal to metal parts that do not require any greasing and it also has a control lever with three-positions of up, neutral and down. |
Specifications :
|
- Available standard capacity: 2500 Kgs., Fork Length 1150,Width 535.
|
- Available capacity options: 2000 Kgs, 2500 Kgs, 3000 Kgs, 5000 Kgs.
|
- Available options: manual, weight scale, battery operator.
|
- Choice: Special fork length, width, wheels & capacity as per requirement.
|
|
Inquiry for Manual Hydraulic Hand Pallet Truck FI-009
|
|
|
|
|
High Lift Hand Pallet Truck |
|
 |
We are equipped with all the facilities required in manufacturing of excellent high lift hand pallet trucks. Our talented team of engineers has vast experience of this field, hence they always welcome customers’ suggestions and specifications to design and develop the best products. The challenger 08 / 10 AHLPT Hand Pallet Truck is one of the premier quality trucks for materials handling. |
Feature :
|
- 800 / 1000 kg capacity hand pallet truck.
|
- Easy to pull chassis - Ideal for regular light duties and in the back of lorries.
|
- Hardwearing nylon rollers.
|
- Single nylon load rollers for great maneuverability.
|
- Totally sealed pump unit (impervious against air, water or dirt) incorporating an overload release valve.
|
- One - piece "C" section forks for greater strength.
|
- Fully adjustable push rods to aid level running.
|
- Powder coated paint finish for longer life.
|
- Bushed metal-to-metal parts - No need to grease!!
|
- Main parts two -year warranty.
|
|
Inquiry for High Lift Hand Pallet Truck
|
|
|
Battery Operated Pallet Truck FI-010 |
|
 |
We manufacture and supply excellent Electric Pallet Trucks, which are engineered by our well-trained, experienced and qualified professionals. They are efficient to realizing wide requirements of buyers. All the Electric Pallet Trucks supplied by us are available at sensible price range and delivered on time. Advanced ergonomics, engineering, materials and the best quality electrical, hydraulic and mechanical components are developed into our Electric Pallet Trucks. Other features include programmable electric hand control, which make a safer, more efficient and more easily maintainable Electric Pallet Trucks. |
Advantages :
|
Electrical System :
|
- 24 volt electrical system incorporating – Transistor "MOSFET" CURTIS, microprocessor controlled with onboard service diagnostic capability.
|
- The controller provides many benefits such as maximum energy efficiency, reduced maintenance and infinite speed control capacity.
|
- Through a flash code signaled by an LED - 17 detectable faults can be recognized.
|
- Using an optional handset, faults can be displayed digitally.
|
- Controller settings are programmable, which will be done by our service personal only.
|
- An impact button provides emergency stop, which makes the power cut off to all components in case of any emergency and which is easily accessible to the operator.
|
- The display console is placed directly in the operator field view and indicates the battery charge status.
|
- Contactors of CURTIS/ALBRIGHT – a.Forward/Reverse, b. Main Contactor,c.Pump Contactor, with which we can operate at high current range.
|
- The control and power circuits are operated through fuses for protection.
|
- All wiring & power controls are number coded.
|
- The safety-reversing device on the tiller head prevents the operator being squeezed between the tiller arm and obstacles behind.
|
Options :
|
|
|
- Sloping fork for paper roll
|
|
Inquiry for Battery Operated Pallet Truck FI-010
|
|
|
Hydraulic Reel Pallet Truck FI-009 |
|
 |
We manufacture a range of Hydraulic Wrap Beam Pallet Truck that facilitates in the smooth and easy movement of warp beam or rolls. The beam flanges are rested on the trolley while transporting. Equipped with premium quality seals and wipers that are the best in India, these pallet trucks are appropriate for carrying beams with width upto 3800 mm, beam flange diameter from 800 mm to 1250 mm. |
Inquiry for Hydraulic Reel Pallet Truck FI-009
|
|
|
| |
Steel Pallet Wooden Pallet FI-027 |
|
 |
| MS and wooden pallets |
| capacity |
: |
500 to 5000 |
| size |
: |
1200 X 1200 |
| height |
: |
600 mm. |
| pallet gape |
: |
110 mm. |
made from ms angle, ms sheet, ms pipe. |
as per clients requirements. |
|
Inquiry for Steel Pallet Wooden Pallet FI-027
|
|
|
| |
Mettle Pallet with Wire Net Box FI-028 |
|
|
 |
| MS and wooden pallets |
| capacity |
: |
500 to 5000 |
| size |
: |
1200 X 1200 |
| height |
: |
600 mm. |
| pallet gape |
: |
110 mm. |
made from ms angle, ms sheet, ms pipe, ms wire net. |
as per clients requirements. |
|
Inquiry for Mettle Pallet with Wire Net Box FI-028
|
|
|
|
|
|
|
|
